6mm stainless steel metal fiber laser cutting machine

  • 1 - 4 Sets
    $72,000.00
  • >=5 Sets
    $65,000.00
Model Number:
LF-PE
Power(W):
500W / 1000W / 2000W / 3000W/4000W
Lead Time:
Quantity(Sets) 1 - 1 2 - 5 >5
Est. Time(days) 20 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
Applicable Material:
Metal
Laser Type:
Fiber Laser
Cutting Area:
3000*1500,4000*2000,6000*2000
Cutting Speed:
0-40000mm/min
Graphic Format Supported:
AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Application:
Laser Cutting
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Condition:
New
Cutting Thickness:
25mm
CNC or Not:
Yes
Cooling Mode:
Water Cooling
Control Software:
Cypcut
Place of Origin:
Shandong, China
Brand Name:
Leapion
Certification:
CE, ISO, SGS
Warranty:
3 years
Laser Source Brand:
MAX
Laser Head Brand:
Raytools
Servo Motor Brand:
FUJI
Guiderail Brand:
HIWIN
Control System Brand:
Cypcut
Key Selling Points:
High-accuracy
Product name:
Fiber Laser Metal Cutting Machine
Laser power:
500W / 1000W / 2000W / 3000W/4000W
Cutting materials:
Stainless Steel Carbon Steel Etc( Metal Laser Cutting Machine )
Laser source:
MAX IPG RAYCUS
Working area:
1500mmX3000mm / 2000mmX4000mm / 2000mmmX6000mm
Control system:
Cypcut Control System
Transmission:
Taiwan YYC Gear
Laser head:
Raytools
Driving system:
Japan Yaskawa Servo Motor
Compatible software:
CorelDraw AutoCAD Photoshop
Supply Ability
Supply Ability:
50 Set/Sets per Month
Packaging & Delivery
Packaging Details
PLYWOOD CASE
Port
Qingdao/Ningbo/Shanghai/Dalian/Tianjin
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 2 - 5 >5
Est. Time(days) 20 30 To be negotiated
Video Description
PRODUCT DESCRIPTION

Leapion fiber laser cutting machine LF-PE use the world top brand parts,Raytools fiber laser head ,the laser head can automatically focus, and imported Japan Yaskawa servo motors and drives, high precision, high speed, large torque, performance is stable and durable, ensure the high speed operation of the whole machine.Chinese top brand fiber laser source Max, high power ,high precision.Top brand control system : Cypcut control system, with automatic layout optimization.

Leapion laser, great laser !



Metal Sheet Laser Cutting Machine

Technical Parameters

----------------------------------------------------------------
Moel No.
LF-6020PE
LF-3015PE
LF-4020PE
Working Area
6000X2000mm
3000X1500mm
4000X2000mm
Laser output power
500W / 750W / 800W / 1000W / 1500W
Repeat Repositioning Accuracy
±0.03mm
Accuracy of Positioning
±0.02mm
Maximum Speed
80M/Min
Maximum Acceleration
0.8G~1.0G
MACHINE ADVANTAGE

Fiber metal laser cutting machine adopts imported rail and heavy racks from Taiwan, Japanese Panasonic servo motor and driver and American laser mech laser head. All this parts match well with each other, machine’s stability is great. Our this fiber not only can cut stainless steel, carbon steel, also can cut some high reflected materials, such as the aluminum and copper. Meet some customer ' s needs.


DETAIL IN KIND SHOOTING


CUTTING PARAMETER

The cutting ability of our fiber laser cutting machine are below :


SUPPORT FORMAT

The format that our software can support on the fiber laser cutting machine.


WARRANTY

We will give you 3 years warranty, so you don't have to worry about the after-sales .
We will also send you new parts if there's any parts broken by non-human issues.

SAMPLES

Our leapion high quality 3015 fiber laser cutting machine is usually used to cutting steel sheet or steel pipe, It can be used in the Aluminium, carbon steel and stainless steel.

MACHINE UPGRADES

You can also select these upgrades parts machine, to make your machine better.

Upgrade machine model

Upgrade fiber laser cutting machine to a high model , leapion 3015H model

Smoke purifier exhaust system

Removes dust and gas generated during laser processing

Different laser power

The power of each laser can be changed according to the specific cutting requirements. achieve the effect of multi-purpose.

CERTIFICATIONS

The certifications of Leapion company.

SERVICE

___________________________

2 years guarantee of the whole machine and we give lifetime maintenance free of charge.

___________________________

Free training to make sure you master the operating of machine at our factory.

___________________________

24 hours online services through Whatsapp, Skype, Email or on the phone.

___________________________

Engineers available for overseas training and after-sale services.

___________________________

Contact me at any time if you have any questions about the machine.

___________________________

Friendly English version manual and operation video CD disk.

OUR COMPANY

>>>>>>

Leapion in laser machine business since 2007, we are a global manufacturing company producing
Laser engravers, laser markers,

>>>>>>

CNC Router, UV inkjet printers for various applications such as signage, advertising, Woodworking furniture.
Leapion Laser is becoming the word's TOP in the laser engraving, cutting and marking industry. We are innovators. We are problem solvers.

>>>>>>

We are committed to designing and manufacturing the highest-quality laser systems and cnc router machine.
Leapion original concept was to bring CO2 laser engraving systems to both commercial customers, small business owners and the home craftsman.

FAQ
How to operate the machine ?
We will deliver English manual and video with the machine to you. If you still need our help, please contact us.
How can I get the sample to check you quality ?
If you want to marking sample to check the quality, we can help you do this. first you need to provide the logo or design to us, free mark samples can be provided.
Does the machine can be customized according to my requirements ?
Sure, we have a strong technical team and have rich experience. Our goal is to make you satisfied.
Can you arrange the shipment for me ?
We can arrange the shipment for our clients by sea or by air. Trading terms FOB, CIF, EXW are available.
